Cambered Axles
Oil bath axles keep bearings evenly and completely lubricated.
The 14GN from Big Tex Trailers is our medium-duty, single-wheel gooseneck. This model combines many of unique Big Tex features-low-profile decks, LED lights, treated floor, dual jacks and an adjustable coupler-providing a professional-grade trailer that delivers for an exceptional value.
Interested in purchasing this trailer?
| AXLE | (2) 7,000# Quick Lubricating w/Electric Brakes |
|---|---|
| JACK | Dual 12,000# Drop Leg Side Wind (Bolted On) |
| NECK | 12" I-Beam, 14# |
| TIRE | ST235/80 R-16 Load Range E |
| FLOOR | 2" Treated Pine or Douglas Fir* |
| FRAME | 12" I-Beam, 14# |
| WHEEL | 16" x 6"; Black Mod 8 Bolt |
| FINISH | Superior Quality Finish is Applied for a Highly Decorative and Protective Finish. |
| LIGHTS | L.E.D. D.O.T. Stop, Tail, Turn & Clearance |
| COUPLER | 2-5/16" Ball Adjustable Pipe |
| DOVETAIL | 5 Cleated Dovetail w/5 Double Hinged, Spring-Assisted Flip-Over Ramps |
|---|---|
| G.V.W.R. | 15,900# |
| ELEC. PLUG | 7-Way RV |
| HITCH TYPE | Gooseneck |
| SIDE RAILS | 5" Channel w/Rub Rail, Stake Pockets, and Chain Spools |
| SUSPENSION | Multi-Leaf Slipper Spring w/Equalizer |
| CROSSMEMBERS | 3" Channel |
| FINISH (Prep) | Steel is Cleaned to Ensure a Professional Smooth Finish. |
| SAFETY CHAINS | 3/8" Grd. 70 w/Safety Latch Hook (2 each) |
| G.A.W.R. (Ea. Axle) | 7,000# |
| Model | Weight | Description |
|---|---|---|
| 14GN-20+5 | 4,780# | 102" x 20' + 5' Single Wheel Tandem Axle Gooseneck |
| 14GN-22+5 | 4,980# | 102" x 22' + 5' Single Wheel Tandem Axle Gooseneck |
| 14GN-25+5 | 5,280# | 102" x 25' + 5' Single Wheel Tandem Axle Gooseneck |
| 14GN-28+5 | 5,580# | 102" x 28' + 5' Single Wheel Tandem Axle Gooseneck |
| 14GN-30+5 | 0# |
Oil bath axles keep bearings evenly and completely lubricated.
Protected wiring, inside the framing or in protected channels, with access to junctures.
Dexter Axles outperform all others for strength and a smooth ride.
LED lighting is brighter and lasts longer.
Nev-R-Adjust Brakes ensure safety and automatically adjust to proper clearances during travel.
Flexible sidewalls result in reduced fuel consumption and produce a softer ride.
| Category | Description |
|---|---|
| BODY | Blackwood Pro Rubber Infused Floor |
| BODY | Removable Deck on the Neck- Bolt On (8 W x 6 L) |
| BRAKES | Electric Over Hydraulic Brakes (Drum) |
| CARGO CONTROL | 4" Sliding Winch |
| CARGO CONTROL | 4" Weld-On Winch |
| CARGO CONTROL | 4" x 30 Strap |
| CARGO CONTROL | 5/8" D-Ring |
| CARGO CONTROL | Low Profile Tool Box 15" x 15" x 36" (Side Mount) |
| CARGO CONTROL | Sliding Winch Track (Per 6 Section) |
| JACK | Dual 2-Speed Landing Gear |
| JACKS | Dual Electric Over Hydraulic Jacks by Stillwell |
| RAMPS | (2) 5 MEGA Ramps |
| RAMPS | 8 Rear Slide-In Ramps (Straight Deck Only) |
| RAMPS | No Dovetail Option (Deletes Dovetail and Ramps) |
| TIRE/WHEEL | Tire and Spare Upgrade (ST235/85 R-16 LR-G) |
Big Tex Trailers reserves the right to change price, design, material and/or specifications without notice or obligation.
