Pro Series Drive-Over Fender Equipment/Car Hauler
A pro-level firm foundation for equipment and cars, the 10DF Pro Series Drive-Over Fender Equipment/Car Hauler is powered by two 5,200-pound axles. It has a 36” self-cleaning cleated dovetail to provide superior load-in traction, and a front stop rail, D–rings, and rub rail to help secure whatever you’re hauling. Whether you’re hauling a tractor to a jobsite or a hot rod to a car show, this trailer has the features and the muscle to make it happen.
Forward, self-adjusting brakes make brake maintenance a breeze. The system automatically adjusts the brake shoes as they wear down, eliminating the need for manual adjustments.
Fast and Easy Hitching
The Demco EZ Latch Coupler is built to last and provides a fast and easy connection, and its automatic latching system securely locks when lowered—saving you both time and effort.
Get a Grip While You Load
Get a boost of confidence as you load in or out with our 36” cleated dovetail. It provides excellent traction and prevents slipping, keeping you moving through your task smoothly.
Diamond-Plate Drive-Over Fenders
These fenders live up to their tough look with a strong construction you can even drive on.
0 of 0
|Model||Pull Type||GVWR||Empty Weight||Cargo Capacity||Bed Length||Bed Width||A||B||C||Tongue Length|
|10DF-19+3||Bumperpull||9990 lbs||3650 lbs||6340 lbs||22'||102"||264"||153"||111"||57-3/4"|
|10DF-17+3||Bumperpull||9990 lbs||3330 lbs||6660 lbs||20'||102"||240"||138"||102"||57-3/4"|
|10DF-15+3||Bumperpull||9990 lbs||3200 lbs||6790 lbs||18'||102"||218"||128"||90"||57-3/4"|
|Standard Feature||Available Options|
|Axles||2 - 5,200# Premium, Cambered Axles with Quick-Lubricating Hubs|
|Brakes||Forward Self-Adjusting Electric Brakes on Both Axles|
|Suspension||Multi-Leaf Slipper Spring w/ Equalizer|
|Coupler||2-5/16" Ball, Adjustable Demco EZ Latch Coupler||Adjustable Pintle in Channel in Lieu of Coupler|
|Safety Chains||1/4" Grade 70 w/ Safety Latch Hook (2 ea)|
|Jack||8,000# Drop-Leg Jack (Side Wind)|
|Front Stop Rail||3/16" Fabricated Front Stop Rail|
|Floor||Treated Pine Floor||Blackwood Pro Rubber Infused Lumber Floor (per linear foot) 1/8” Diamond Plate Steel Floor (Per Square Foot)|
|Fenders||3/16" Diamond Plate Drive Over Fenders|
|Ramps||5' Rear Slide in Ramps w/ Stabilizer Jacks||5' Knee Ramps (19") In Lieu of Slide-in Ramps|
|Dovetail||3' Cleated Dovetail|
|Stake Pockets||Stake Pockets Along Both Sides (Quantity Varies by Length)|
|Trailer Plug||7-Way RV|
|Lights||Recessed, Grommet-Mounted L.E.D. Lighting|
|Wiring||Sealed, Modular Cold-Weather Wiring Harness|
|Tires||ST225/75 R-15 Load Range E Radial Tires|
|Spare Mount||Front Spare Tire Mount|
|Spare Tire||Not Included||Spare Tire & Wheel (ST225/75 R-15 LR-D)|
|Paint Type||Professional Finish w/ Primer Standard|
|Paint Color||Black||Red Grey White Desert Tan Jet Blue Slime Green Implement Green Equipment Orange Medium Yellow|
|Rubrail||Rub Rail Along Both Sides|
|Tie-Downs||(6) 5/8" D-Rings||Extra 5/8" D-Rings Recessed D-Ring in Floor (Steel Floor Only)|
|Break-Away Kit||Complete Breakaway System w/ Zip Breakaway Cable|
