Gooseneck with 2-5/16" Adjustable Pipe Coupler
Gooseneck configuration for strength and stability.
The 14GP Heavy Duty Pipe Top Gooseneck Trailer is one of our most capable (and most popular) pipe-top equipment trailers. This unit combines all of the great features of our Big Tex 14K gooseneck trailers with a pipe rail for added strength and security.
Interested in purchasing this trailer?
| AXLE | (2) 7,000#, Quck Lubricating w/Electric Brakes |
|---|---|
| JACK | 12,000# Drop Leg Jack- Side Wind |
| NECK | 10" I-Beam |
| TIRE | ST235/80 R-16 Load Range E |
| FLOOR | 2" Treated Pine or Douglas Fir* |
| FRAME | 5" x 3" x 5/16" Angle |
| WHEEL | 16" x 6"; Black Mod 8 Bolt |
| FINISH | Superior Quality Finish is Applied for a Highly Decorative and Protective Finish. |
| LiGHTS | L.E.D. D.O.T. Stop, Tail, Turn & Clearance |
| COUPLER | 2-5/16" Ball Adjustable Pipe |
| FENDERS | 9" x 72" Double Broke Diamond Plate w/Back |
| G.V.W.R. | 14,000# |
|---|---|
| TOP RAIL | 3" Square Tubing |
| UPRIGHTS | 15" Tall, 3" x 2" x 3/16" Angle |
| ELEC. PLUG | 7-Way RV |
| HITCH TYPE | Gooseneck |
| SUSPENSION | Multi-Leaf Slipper Spring w/Equalizer |
| CROSSMEMBERS | 3" Channel on 16" Centers |
| FINISH (Prep) | Steel is Cleaned to Ensure a Professional Smooth Finish. |
| SAFETY CHAINS | 3/8" Grd. 70 w/Safety Latch Hook (2 ea) |
| G.A.W.R. (Ea. Axle) | 7,000# |
| Model | Weight | Description |
|---|---|---|
| 14GP-20 | 3,450# | 83" x 20' HD Gooseneck Tandem Axle Pipe Top Lowboy |
| 14GP-24 | 3,850# | 83" x 24' HD Gooseneck Tandem Axle Pipe Top Lowboy |
Gooseneck configuration for strength and stability.
Simple to maintain and completely submersible with no disassembly required.
Industry-leading axles with a smooth, reliable ride.
Ensure safety and automatically adjust to proper clearances during travel.
Coated anchor slides help to keep every haul in place and secure.
LED lighting is brighter and lasts longer.
| Category | Description |
|---|---|
| BODY | 1/8" Diamond Plate Steel Floor |
| BODY | 2 High Sides (Open) |
| BODY | 3 High Sides (Open) |
| BODY | 4 High Sides (Open) |
| BODY | Blackwood Pro Rubber Infused Floor |
| BODY | Enclose Sides w/ Expanded Metal |
| BODY | Enclose Sides w/ Sheet Metal |
| CARGO CONTROL | 5/8" D-Ring |
| CARGO CONTROL | Additional Stake Pockets |
| CARGO CONTROL | Lockable Tool Box Between Gooseneck Risers (Dual Jacks Required) |
| JACK | Dual 12,000# Drop Leg Jacks |
| RAMPS | 4 Heavy Duty Integrated Ramp Gate w/Gas Shock Assist in Lieu of Ramps |
| RAMPS | 5 Heavy Duty Integrated Ramp Gate w/Gas Shock Assist in Lieu of Ramps (Split Gate) |
| RAMPS | 5 Stand up Ramps in Lieu of Slide In |
| TIRE/WHEEL | Spare Tire (ST235/80 R-16 LR-E) |
| TIRE/WHEEL | Spare Tire Upgrade (ST235/85 R-16 LR-G) |
| TIRE/WHEEL | Tire Upgrade (ST235/85 R-16 LR-G) |
Big Tex Trailers reserves the right to change price, design, material and/or specifications without notice or obligation.
